| 1. DC VOLTAGE | Range : 6V - 1000V |
| Accuracy : ±(0.5% + 3) / ±(0.8% + 10) | |
| Resolution : 0.001 V - 1 V | |
| 2. AC VOLTAGE (T-RMS) | Range : 6V - 750V |
| Accuracy : ±(0.8% + 3) / ±(1.2% + 10) | |
| Resolution : 0.001 V - 1 V | |
| 3. DC CURRENT | Range : 600 µA - 10A |
| Accuracy : ±(1.2% + 10) / ±(2.0% + 30) | |
| Resolution : 0.1uA - 0.01 A | |
| 4. AC CURRENT (T-RMS) | Range : 600 µA - 10A |
| Accuracy : ±(1.2% + 10) / ±(2.0% + 30) | |
| Resolution : 0.1uA - 0.01 A | |
| 5. CAPACITANCE | Range : 60 nF - 30 mF |
| Accuracy : ± (3.5%+20) / ±(5% + 3) | |
| Resolution : 10 pF - 10 uF | |
| 6. FREQUENCY | Range : 10 Hz - 10 MHz |
| Accuracy : ±(0.1% + 5) | |
| Resolution : 0.01 Hz - 10 kHz | |
| 7. RESISTANCE | Range : 600 Ω - 40 M Ω |
| Accuracy : ± (0.8%+5) / ± (0.8%+3) / ±(2.5% + 3) | |
| Resolution : 0.1 Ω - 10 kΩ | |
| 8. OPERATING TEMPERATURE | 0 ~ 40°C |
| • Display Mode: LCD | |
| • Display Counts: 6000 | |
| • Digits : 3 5/6 | |
| • Auto Ranging . | |
| • Sampling rate: 3 Times per second | |
| • Max / Min record function | |
| • True RMS | |
| • AC/DC Voltage | |
| • AC/DC Current | |
| • A / D Conversion measurement | |
| • Resistance | |
| • Capacitance | |
| • Frequency | |
| • Diode Test | |
| • Continuity Test | |
| • NCV | |
| • Data Hold | |
| • Auto Power Off | |
| • Low Voltage Indication | |
| • Relative measurement | |
| • Overload protection |
| ASIN | B0DK745NLM |
|---|---|
| Best Sellers Rank | #54,749 in Industrial & Scientific (See Top 100 in Industrial & Scientific) #172 in Clamp Meters |
| Date First Available | 17 October 2024 |
| Manufacturer | SHREYANS ENTERPRISES, 002, 9th Avenue Business Park, Chamrajpet 5th Main Road, Bangalore, India |
| Packer | avsCARTindia New Delhi-110007, Email: avsenterprises16@gmail.com |
| Item Dimensions LxWxH | 20 x 8 x 4.5 Centimeters |
| Net Quantity | 1 Set |
| Generic Name | CLAMP METER |
